Designed for connecting Multi-Lane packing machine. Especially for sachets parallel weighing.
FEATURES
- Number of lanes software configurable from 2 to 12 lanes
- Standard model with 6 lanes.
- Equipped with dynamic loadcell and high speed DSP
- Automatic product Guide and Zero Tracking
- Points configurable real-time weight curve display
- Metric/Imperial and Normal/EU regulation shift
- 13 inches touch screen with android system which support multiple languages
- Large system memory which supports long term recording, fast seeking and recalling
- Supports graphic based production statistic and analysis
- Equipped with BLDC motor which is performing high speed and low dither
- Records could be export to USB drive (CSV format)
- Data export by ethernet port
- Drop off rejector with bottom conveyor feed out
- Tool Free conveyor remove
- SUS304 Frame
SPECIFICATIONS
Model | CWC-ML6 |
Range | 10~550g |
Accuracy | 0.3g |
Platform Size (L*W) | 440*80mm |
Belt Width | 60mm |
Max. Speed | 150ppm/Lane |
Rated Power | 1100W |
Effective Work Size (L*W) | 400*80mm |
Resolution | 0.01g |
Loadcell type | Strain-Gauge |
Belt Speed | 10～54m/min |
Rejector | Drop off |
Power Supply | AC100～240V, 50～60Hz, Single Phase |
Accessories | Signal tower, USB, RS-232, Ethernet |
※Accuracy and speed depends on product status, form, and tandem space.
Application
A compact design of parallel check weigher which mostly connects to a multi-lane packing machine for several kinds of sachets such as powder, granula, and liquid.
