Our Products
Widely used for meats, seafoods, fruits, and vegetables, automatic weight batching.
MACHINE USAGE
- Avoids a shortage of weight
- Reduces material costs
- Improves work efficiency
FEATURES
- HBM quality loadcell
- Optimized combination algorithm
- Combination mode: Speed/Accuracy
- Auto Zero Tracking and Automatic/Manual Tare
- Recipe combination: maximum 4 units
- Unit shift: g, kg, LB, oz
- Automatic fault diagnosis, weighing unit
- Automatic/manual isolation
- Records graphic statistic and USB drive export
- 10 inches touch screen with android system, which supports multiple languages
- Tool free platform removable
SPECIFICATIONS
|
Model |
MHW-M10 |
MHW-M12 |
MHW-M14 |
MHW-M16 |
|
|
Max. Batch |
10Kg |
12Kg |
14Kg |
16Kg |
|
|
Accuracy |
1g |
||||
|
Range (Unit) |
1Kg / 3Kg/5Kg |
||||
|
Platform Size (L*W) |
215*155mm / 200*125mm |
||||
|
Max. Speed |
40 batches/min |
||||
|
Rated Power |
50W |
70W |
90W |
110W |
|
|
Resolution |
1g |
||||
|
Loadcell type |
Strain-Gauge |
||||
|
Operation condition |
0~40 degree Celsius, humidity 30~85% (without condensation) |
||||
|
Protection level |
IP65 |
||||
|
Power Supply |
AC100～240V,50～60Hz, Single Phase |
||||
|
Weight |
50Kg |
55Kg |
60Kg |
65Kg |
|
|
Accessories |
USB, RS-232, Ethernet |
||||
※Accuracy and speed depends on product status, form, and feed-in operation.
