Suitable for various of large size packages, especially for carton boxes.
FEATURES
- Dual Loadcell with high speed DSP
- Automatic product Guide, Zero Tracking and Trend Follow Up
- Barcode scanner and inkjet optional for automatic recipe shift and print
- Metric/Imperial and Normal/EU regulation shift
- 13 inches touch screen with android system which support multiple languages
- Large system memory which supports long term recording, fast seeking and recalling
- Supports graphic based production statistic and analysis
- Records could be export to USB drive (CSV format)
- Data export by ethernet port
- Platform size expandable and weighing range extendable
- SUS304 frame
SPECIFICATIONS
Model | CWC-M3-700 |
Range | 100~60000g |
Accuracy | ±1‰ |
Platform Size (L*W) | 1006*700mm |
Belt Width | 700mm |
Max. Speed | 30ppm |
Rated Power | 300W |
Effective Work Size (L*W) | 950*700mm |
Resolution | 1g |
Loadcell type | Strain-Gauge |
Belt Speed | 10～33m/min |
Rejector | Roller conveyor with pusher |
Power Supply | AC110/220V,50-60Hz, Single Phase |
Accessories | Signal tower, USB, RS-232, Ethernet |
※Accuracy and speed depends on product status, form and tandem space.
