Technical parameters of 6-head self-flow filling machine
| |
Number of filling heads | 6 Heads |
Filling capacity | 0.5L-5L |
Filling form | Multiple nozzles into bottle bottom fast and slow filling |
Filling speed | 6-8 Bottle / min (4L bottles) |
Filling accuracy | ± 1% |
Pressure | 0.6-0.8 Mpa |
Transport motor | 750W Frequency Control motor |
Power | Approximately 2.2KW/380V Three-phase wire |
Main tank capacity | 200 liters (with level switch, inlet tube inserted into the bottom, trough cover to prevent foam overflow) |
Linear capping machine technical parameters
| |
Lid putting form | Put the lid manually (the bottle with nozzle needs to be put by hand and make sure the direction is the same) |
Suitable for specifications | According to the model provided by the customer |
Capped form | 8 rounds of rubbing screw cap |
Speed | 20-30 Bottle/min |
Material | The rack is made of 304 stainless steel |
Program control | PLC+ Touch screen |
Total power | 200W |
Pressure | 0.6-0.8 Mpa |
Conveyor | Shared with filling machine |
We stand by your side, no matter your needs
VYTE Industrial Solutions operates in the field of industrial production, packaging, and labeling machinery, with bottling, filling, screwing, capping, vacuum, wrapping, sealing, and labeling machines. It aims at small and large production lines in the food, pharmaceutical, cosmetic, and chemical industries.
